MEM
CUFF
AIR HOSE
AIR CONNECTOR PLUG
LCD DISPLAY
USER SELECT SWITCH
MEM BUTTON
START/STOP BUTTON
SET BUTTON
BATTERY COMPARTMENT
Monitor Components
List
1.Blood Pressure Monitor
(TMB-986)
4. User manual
3. 4 x AAA Batteries2. Cuff (22~42cm)
(Type BF Applied Part)
MEM
5
4
LCD display signal
SYMBOL DESCRIPTION
Systolic blood pressure High pressure result
Diastolic blood pressure Low pressure result
EXPLANATION
Pulse Pulse/minute
Deflating CUFF air is exhausting of deflating
Time (hour:minute) Currently time
Memory
If “M” shows, the displayed measurement
values is from the memory.
mmHg
Measurement Unit of the blood pressure
1mmHg
Low battery Batteries are low and need to be replaced
Shocking remainding Shocking will result in inaccurate
Average The average of blood pressure
Recalling The erecords will be showed
Irregular heartbeat
Irregular heartbeat
User A The User A is chosen
User B The User B is chosen
Grade The grade of the blood pressure
Date
Heartbeat
“M” shows the month, “D” shows the day
Heartbeat detection during the measurement
Component list of
pressure measuring system
1 Cuff
2 Air pipe
3 PCBA
4 Pump
5 Valve
