Assembly Instructions
Unpacking
Carefully remove all packing material from the bicycle and inspect the bike for any damage which may have
occurred during shipping.
Front Wheel
Remove the fork protection (Img. 1). Mount the front wheel onto the fork. Fasten the 15mm nuts on both
sides lightly. After the front wheel has been centered make sure that the nuts are completely t fastened.
(Img. 2).
Front Light & Mudguard
Tighten front light and mudguard onto fork crown. (Img. 3&4). Make sure the front light has a vertical
position. (Img. 5).
z Philipps Head Screwdriver
z 4mm, 5mm, 6mm Allen Key
z Wrench 8mm, 9mm, 10mm, 13mm, 14mm, 15mm & 19mm
z Side Cutter
Img. 1 Img. 2
Img. 3 Img. 1
Img. 5
