Optional Equipment 37
© Travis Industries 100-01273 4150514
3. Replace the floor firebrick to complete the installation.
4. Remove the cover and gasket using a 5/16” nutdriver. See the photos below.
5. Install the housing as shown below.
NOTE: The gasket’s hole patterns are unique. The housing must be re-installed in the same
configuration. If the holes are not aligned, rotate the gasket 90.
To Next Page
