6 Stove Installation (for qualified installers only)
© Travis Industries 100-01273 4150514
Installation Options
Masonry Fireplace Insert
Zero-Clearance (Metal) Fireplace Insert
Features
3 Cubic Foot Firebox Volume
Single Air Control
Accepts Logs Up to 24" Long
Steel Plate Construction (Up to 5/16")
Heavy Duty Refractory Firebrick
Standard High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 1,500 to 2,500
Maximum Burn Time Up to 12 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
This model was tested for efficiency using method B415.1-10 and was determined to have a weighted average
Higher Heating Value (HHV) Overall Heating Efficiency (OHE) of 80.3%.
Dimensions
Figure 1
(a) Measure clearances from base of insert (b) Fireplace Opening
Emissions and Efficiency
This heater meets the 2015 U.S. EPA’s crib wood emission limits for wood heaters sold after May 15,
2015. Tested to Method 28, 5G2 this heater has been shown to deliver heat at rates ranging from 8,500
to 35,300 BTU/hr and an emission value of 0.58 g/h.
6.25"
159 mm
530 Lbs. (236 Kg)
6" (153mm) Dia.
19"
483mm
23.5"
597mm
a
b
31" 788mm
22"
559mm
20.75"
528mm
9.75"
248mm
To Next Page
