12
EN
Installation
1/2”
IN
OUT
IN
ø40
Filters*: retain impuri-
ties and oxides (indis-
pensable if the water
comes from a well)
Softener*: reduces the
water hardness to opti-
mal values
Gate valve*: shuts
off the water ow
Drain Valve*: useful for
emptying the pipes dur-
ing maintenance or at
the end of the season.
Connection to the minipool using the 1/2 inch female hose pro-
vided.
If the minipool is installed outdoors provide an adequate thermal
insulation of the pipes. It is the plumber's responsibility to choose
the type of materials to be used.
Connect the drain of the oor minipool. The
plumber is responsible for the choice and type
of materials to be used and the verication of
compliance with anti-pollution standards.
* The images are purely indicative: the model and type must be chosen by the plumber based on the characteristics of the water and the cur-
rent system.
EXAMPLE OF PRE-INSTALLATION PLUMBING FOR A MINIPOOL
minipool Phantom
