COMBI 600
ITEMS ENCLOSED
DESCRIPTION OF PARTS
x1
x1
x3
Jig body
Label
Postform joint slot
Female joint bush location hole
Length setting stop location hole 225mm
Length setting stop location hole 300mm
Length setting stop location hole 325mm
Length setting stop location hole 400mm
225
300
400
500
600
6.6
600
GUARANTEE
햲
햳
햴
햵
햶
햷
햸
햹
Length setting stop location hole 500mm
Length setting stop location hole 600mm
Length setting stop location hole 616mm
Male joint bush location hole
Bolt recess bush location hole
Connecting bolt recess slot
Alloy location bush
햺
햻
햽
햾
햿
헀
헁
ITEMS REQUIRED
■ 1/2” plunge router
■ 30mm guide bush
■ 12.7mm diameter x 50mm cut router cutter with 1/2” shank
■ Trestles x2
■ Clamps x2
■ Hand tools
■ Panel connector bolts
■ Wooden biscuits Size No.20
■ Sealant
