-12-
CRT MK2
Mounting the No-Volt Release Switch
■ The no-volt release switch serves as start-up
protection. When the router is plugged in and
its on/off switch depressed, the router starts
only after the green switch is pressed.
■ Switch off the router using the red button.
■ Attach the no-volt release switch to the table
leg with the screws provided.
■ Plug the router into the socket.
IMPORTANT:
Always remove the plug of the
No-Volt Release Switch from the
power source before making any
adjustments.
Insert Rings
■ For router cutter diameters up to 50mm,
insert rings can be fitted. They serve to keep
the opening between the tool and the routing
table as small as possible.
■ The diameter of the insert ring should be
approximately 4mm larger than the cutter
diameter.
Max. router cutter
size without insert
rings:
- 53mm Ø max
Max. router cutter
sizes with insert
rings:
