CRT MK2
Contents
Items Enclosed _______________________2
Description of Parts ___________________2
Safety Precautions
- Cutter Care _________________________3
- Useful Advice ________________________3
Assembly _________________________4-13
- Identification of Router Mounting Holes ____6
- Fitting router to fixing plates ___________6-7
CRT/Mk2 Fixing Plates _______________8-9
Adjustment
- Fence Adjustments ___________________14
- Workpiece Support ___________________14
- Cutting Depth/Cutting Height ___________14
Optional Accessories ______________15-19
Operation
- Edge Moulding with the Back Fence _____20
- Grooving with the Back Fence __________21
- Full Edge Moulding ___________________21
- Across the grain routing with Mitre Fence _22
- Stopped Moulding ____________________22
- Tenon Cutting _______________________23
- Routing without a Back fence ___________24
- Mounting a Lead-On Pin_______________24
- Profile Working Procedure___________24-25
Producing a Shield ________________26-27
Spare Parts
- Spare Parts List ___________________28-30
- Spare Parts Diagram _______________31-34
Maintenance and Cleaning_____________35
Please read the operating instructions
carefully and keep them together with
your router table.
If you require further technical information or spare parts for this router table,
please call our technical support department on 01923 224681 or your agent.
☎
The following symbols are used throughout this
manual:
IMPORTANT!
Denotes possible risk of personal injury, or
damage to the tool in case of non-
observance of the instructions in this
manual.
Specification
Working height with floor stand accessory
- 1000mm
Back fence height
- 100mm
Back fence extraction point diameter
- 58mm
Table top aperture diameter
- 57mm
Push block max. tenon thickness - 110mm
Weight (without accessories)
approximately 10kg
Intended use
The unit is intended for stationary operation of
routers.
Please remember to return your
guarantee card within 14 days of
purchase.
