IQ422, IQ4NC/00, IQ4NC/12 Controllers Installation Instructions - Mounting TG201264 Issue 12, 04-Feb-2020. Applies to v4.30 3
Installation Instructions - Mounting IQ422, IQ4NC/00, IQ4NC/12
3
Mount Unit on DIN Rail
4
Attach Large Barcode Label to Panel
5
Open Rotating Covers
2
Mounting Requirements (continued)
1
2
3 INSTALLATION (continued)
IQECO: Q3 B_ X73080031
SERIAL No.
IQ422 Q3B_X73080031
TREND IQ41x
23
1
4
DIN Rail end stop
IQ4xx
IQ4xx
IQ4xx
IQ4xx
DIN rail must be earthed (grounded)
Note: To remove from DIN rail see section 4, page 11
