T4 - SPARE PARTS LIST v2.0 09/2007
No. Qty. Desc. Ref.
38 1 Thumb Knob WP-T4/038
39 1 Spring 8mm WP-T4/039
40 1 Base Housing Lock Nut WP-T4/040
41 1 Bolt Hex M6 x 48mm WP-T4/041
42 1 Circlip 17mm WP-T4/042
43 1 Plunge Lock Lever WP-T4/043
44 1 Lower Housing Clamp Spacer WP-T4/044
45 1 Torsion Spring 12mm Dia WP-T4/045
46 2 Grip Knob WP-T4/046
47 2 Plunge Spring WP-T4/047
48 2 Plunge Column WP-T4/048
49 2 Machine Screw Socket M5 x 12mm WP-SCW/12
50 1 Dust Extraction Spout Upper Housing WP-T4/050
51 1 Threaded Pin M5 x 25mm WP-T4/051
52 3 Nut Hex M5 WP-NUT/05
53 1 Threaded Pin M5 x 35mm WP-T4/053
54 1 Threaded Pin M5 x 15mm WP-T4/054
55 1 Stepped Machine Screw M6 WP-T4/055
56 1 Revolving Turret WP-T4/056
57 1 Ball for Revolving Turret WP-T4/057
58 1 Spring for Revolving Turret WP-T4/058
59 1 Set Screw M4 x 5mm slot WP-T4/059
60 2 Set Screw M6 x 8mm WP-T4/060A
61 1 Plastic Base Slider WP-T4/061
62 1 Spring Washer Revolving Guide WP-T4/062
63 2 Machine Screw Csk M5 x 12mm Slot WP-SCW/11
64 2 Machine Screw Csk M5 x 8mm Slot WP-SCW/09
65 1 Guide Rod 8mm x 300mm (pair) WP-T4/065
66 4 Machine Screw Csk M4 x 6mm Pozi WP-SCW/66
67 1 Side Fence Cheeks (pair) WP-T4/067
68 1 Parallel Side Fence Body WP-T4/068
69 1 Spanner Special 17mm A/F WP-T4/069
70 1 Machine Screw Pan M4 x 12mm Pozi WP-T4/070
71 1 Spanner 14mm A/F WP-SPAN/14P
72 1 Hex Key 4mm A/F WP-AP/04
73 3 Machine Screw Csk M4 x 18mm Pozi WP-T4/073
74 2 Washer 6mm x 11mm x 0.8mm WP-T4/074
75 2 Spring Washer 6mm WP-WASH/30
76 1 Spindle Lock Housing WP-T4/076
77 1 Spindle Lock Bracket WP-T4/077
78 1 Spindle Lock Button WP-T4/078
79 1 Spindle Lock Plate WP-T4/079
80 1 Spring for Spindle Lock WP-T4/080
81 1 Dust Spout Lower Housing WP-T4/081
82 1 Switch Base WP-T4/082
83 - - -
84 1 Machine Screw Pan M4 x 14mm Pozi WP-T4/084
85 1 Screw Self Tapping Pan 4mm x 20mm WP-T4/085
86 1 Depth Stop Knob WP-T4/086
87 1 Guide Bush 16mm GB16/B
88 1 Manual MANU/T4
-19-
MANU/T4 v2.0 30/8/07 1:08 pm Page 19
