T4 - SPARE PARTS LIST v2.0 09/2007
No. Qty. Desc. Ref.
1 1 Stator Housing WP-T4/001
2 1 Top Vent Housing WP-T4/002
3 1 Base WP-T4/003
4 1 Spring Washer 4mm WP-T4/004
5 2 Washer 4mm x 7mm x 0.8mm WP-T4/005
6 1 Cable Guard WP-T4/006
7 1 Speed Control Circuit Board 230V T4E WP-T4E/007
1 Speed Control Circuit Board 115V T4EL WP-T4EL/007
8 2 Carbon Brush Cover WP-T4/008
9-- -
10 1 Carbon Brush 230V (1 pair) WP-T4E/010
1 Carbon Brush 115V (1 pair) WP-T4EL/010
11 2 Carbon Brush Holder WP-T4/011
12 2 Spring Washer 5mm WP-WASH/29
13 2 Column End Cap WP-T4/013
14 1 Plunge Locking Screw LH WP-T4/014
15 1 Cable Clamp WP-T4/015
16 1 Screw Self Tapping Pan 4mm x 12mm Pozi WP-T4/016
17 1 Switch 230V T4 WP-T4E/017
1 Switch 115V T4EL WP-T4EL/017
18 1 Push Rod WP-T4/018
19 1 On / Off Lever WP-T4/019
20 - - -
21 1 2 Core Cable with Plug 230V UK T4 WP-T4/021
1 2 Core Cable with Plug 230V Euro T4/EURO WP-T4EURO/021
1 2 Core Cable with Plug 115V UK T4L WP-T4L/021
22 1 Field 240V T4E WP-T4E/022
1 Field 115V T4EL WP-T4EL/022
23 1 Baffle WP-T4/023
24 2 Machine Screw Pan M4 x 63mm Pozi WP-T4/024
25 1 Top Bearing 7mm x 22mm x 7mm 608ZZ WP-T4/025
26 1 Armature 230V with Fan T4 WP-T4E/026
1 Armature 115V with Fan T4EL WP-T4EL/026
27 1 Lower Bearing Housing WP-T4/027
28 1 Lower Bearing 17mm x 35mm x 10mm 6003ZZ WP-T4/028
29 1 Screw Self Tapping Pan 4mm x 14mm Pozi WP-T4/029
30 1 Collar Left Hand Threaded WP-T4/030
31 2 Machine Screw Pan M6 x 55mm Pozi WP-T4/031
32 1 Bearing Lock Plate WP-T4/032
33 1 Collet Spring WP-T4/033
34 1 Collet 6.35mm (
1
⁄
4
”) CLT/T4/635
1 Collet 6mm CLT/T4/6
1 Collet 8mm CLT/T4/8
35 1 Collet Nut CLT/NUT/T4
36 1 Depth Stop WP-T4/036
37 1 Middle Frame WP-T4/037
