Page 7
Procedure
1. Insert the supplied CD-ROM into your drive. If the setup program does not start automatically, run Autorun.exe in the root folder.
2. On the first screen, shown below, click Install Utility, and then click Setup Wizard.
3. Click OK to follow the setup procedures:
(1) Connect MFP/All-in-one machine to Print Server.
(2) Connect both PC and Print Server to Router or Hub.
(3) Power ON MFP/All-in-one.
(4) Power ON Print Server.
(5) Check the LED on the Print Server. Status LED (Green) should be ON and Error LED (Red) is OFF.
To use the LAN interface, the LAN cable needs to be
inserted BEFORE powering ON.
The Wired (LAN) interface should be used for initial
configuration.
Or click Skip if all the above steps have been done already.
4. Select your Print Server, and then click Next to continue.
To Next Page
