52
TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.11n draft 2.0; IEEE 802.11g; IEEE 802.11b
Protocol CSMA/CD
Radio Technology DSSS/OFDM
Data Transfer
Rate
802.11n mode: up to 300Mbps (auto sense)
802.11g mode: up to 54Mbps (auto sense)
802.11b mode: up to 11Mbps (auto sense)
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
Receiver
Sensitivity
802.11n: -70dBm typical @ 300Mbps
802.11g: -72dBm typical @ 54Mbps
802.11b: -84dBm typical @ 11Mbps
TX Power 802.11n: 14dBm typical
802.11g: 15dBm typical
802.11b: 18dBm typical
Network Cables 10BASE-T: 2-pair UTP Cat. 3,4,5 (100 m), EIA/TIA- 568 100-
ohm STP (100 m)
100BASE-TX: 2-pair UTP Cat. 5 (100 m), EIA/TIA-568 100-ohm
STP (100 m)
Frequency Range 2412 ~ 2484 MHz ISM band
Modulation
Schemes
DBPSK/DQPSK/CCK/OFDM
Security 64/128-bits WEP Encryption; WPA, WPA-PSK, WPA2, WPA2-
PSK
Channels
1~11 Channels (US) 1~13 Channels (EU)
Number of Ports LAN: 4 x 10/100Mbps Auto-MDIX Fast Ethernet port
WAN: 1 x 10/100Mbps Auto-MDIX Fast Ethernet port
Physical and Environmental
DC inputs 5VDC 2.5A
Power
Consumption
7W (Max)
Temperature Operating: 0
o
C ~ 40
o
C, Storage: -10
o
~ 70
o
C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 180 x 122 x 30 mm (6.8 x 4.6 x 1.1 inches)
EMI: CE, FCC
