© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-659BRV
15
Note: If the WEP key you have entered does not meet the correct format, the
text color will change to red. Moving your cursor over the WEP Key field will
provide you with helpful tips as to why the key format is incorrect.
Click Save to save the changes.
Note: If you would like to discard the changes, click Undo before you click Save.
For advanced users, to select and configure WEP (Wired Equivalent) with 802.1x which
is the standard for port-based access control (PNAC), also known as Extensible
Authentication Protocol,or called RADIUS, Remote Authentication Dial-In User Service),
select Open, in the Authentication drop-down list.
Note: It is recommended to use WEP using a HEX or ASCII key because it is easier to
setup and simply requires you to create a key compared to 802.1x which requires you to
connect an external RADIUS server and requires more configuration.
Select Open in the Authentication drop-down list.
Note: The 802.1x option is only available when using Open Authentication.
Select the Enable option for 802.1X.
Then click on the Encryption drop-down list and select WEP.
• RADIUS Server IP - Enter the IP address of the RADIUS server.
(e.g. 192.168.10.250)
• RADIUS Port – Enter the port your RADIUS server is configured to use for
RADIUS authentication. Note: It is recommended to use port 1812
• RADIUS Shared Key– Enter the shared secret used to authorize your router
with your RADIUS server.
Click Save to save the changes.
Note: If you would like to discard the changes, click Undo before you click Save.
