TRENDnet User’s Guide
TEW-659BRV
4
Application Diagram
The router is installed in a main office location which is connected to the Internet. A
desktop computer is connected to one of the four LAN ports of the router using an
Ethernet cable (also called network cable) and a laptop is connected wirelessly using its
integrated wireless adapter to connect to the router allowing these computers to access
the Internet. The router is also configured as a Virtual Private Network (VPN) server to
allow secure remote access (over the Internet) to work related files and media located
at the main office to an employee working from an outside home office location.
