© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-726EC
17
Technical Specifications
Hardware
Interface PCI Express 1.0
Standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
LED Indicator Data transmission: blinking
Link established: solid
WPS (Wi-Fi Protected Setup): blinking rapidly
Disconnected: blinks every ten seconds
Power
Consumption
Transmit mode: 670mA max.
Receive mode: 350mA max.
Supported
OS
Windows 8 (32/64-bit), 7 (32/64-bit), Vista (32-bit), XP (32/64-bit)
Dimensions 66 x 55 mm
Weight 45 g (1.6 oz)
Temperature
Operating: 0° ~ 40° C (32° ~ 104° F)
Storage: -20° ~ 75° C (-4° ~ 167° F)
Humidity 90% max. (non-condensing)
Certifications CE, FCC
Wireless
Modulation DBPSK, DQPSK, DSSS, CCK, BPSK, QPSK, 16-QAM/64-QAM with
OFDM
Antenna 2 x 2 dBi dipole detachable antennas with reverse SMA connector
Frequency 802.11b/g/n: 2.400 ~ 2.483 GHz
802.11a/n: 5.150 ~ 5.350 GHz / 5.725 ~ 5.825 GHz (FCC),
5.150 ~ 5.350 GHz / 5.470 ~ 5.725 GHz (ETSI)
Data Rate
(auto
fallback)
802.11a: up to 54 Mbps
802.11b: up to 11 Mbps
802.11n: up to 300 Mbps (for 2.4 or 5 GHz)
Output
Power
2.4 GHz: Typical RF Output Power (tolerance +/- 2dB)
802.11b: 18 dBm
802.11g: 18 dBm
802.11n: HT20: 18 dBm
HT40: 13 dBm
5 GHz: Typical RF Output Power (tolerance +/- 2 dB)
802.11a: 16 dBm
802.11n: HT20: 13 dBm
HT40: 13 dBm
Receiving
Sensitivity
802.11a: -65dBm (typical) at 54 Mbps
802.11b: -76dBm (typical) at 11 Mbps
802.11g: -65dBm (typical) at 54 Mbps
802.11n: -62dBm (typical) at 300 Mbps (for 2.4 or 5 GHz)
Encryption 64/128-bit WEP, WPA / WPA2-PSK, WPA/WPA2-RADIUS
Channels 2.4 GHz: 1~11 (FCC), 1~13 (ETSI)
5 GHz: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC) 36, 40, 44, 48,
52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136,
140 (ETSI)
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual
data throughput and coverage will vary depending on interference, network traffic, building
materials and other conditions.
