8
4. Mounting the Device
1. Remove the mounting plate from the TEW-821DAP.
2. Place the mounting plate on the wall or ceiling where the device will be located, and mark
the location of the screw holes. Ensure that the device has enough clearance to slide on and
off the mounting plate. If you are using a non-PoE router or switch, and external power is
required, ensure that your mounting location has access to an electrical outlet.
3. Drill out the marked screw holes, and insert the plastic wall anchors into the screw holes.
4. Secure the mounting plate, using the screws that came with the device.
5. Place the TEW-821DAP on the mounting plate, and attach the network cable. If you are using
a non-PoE router or switch and require external power, connect the power adapter.
Toll Free English Technical Support
US/Canada: 855-373-4741
Hours: Monday-Friday
7:00 AM- 6:00 PM, Pacific Standard Time.
After hours: 866-845-3673
2
5
4
3
