TRI tool 301SP - 4. SPECIFICATIONS

TRI TOOL INC.
92-0579 Rev. 190612
8
4. SPECIFICATIONS
Figure: 1. Model 301SP Tube Squaring Machine with a Motor
Saddle
Feed Handle
Trigger
Speed Control
8.50”
(215.9 mm)
(82.6 mm)
3.25”
14.50”
(368.3 mm)
Weight with a Motor (Approx.):8.5lbs.(3.9kg)
(varies with Saddle size and type of Motor).
POWER REQUIREMENTS
Model No. P/N
301SP 110 115 VAC +/- 10%, 25 to 60 Hz
301SP 220 220 VAC +/- 10%, 25 to 60 Hz
Model 301SP-A 22 cfm at 90 psi (10 L/s at 621 kPa)
