7. CHIP GUARD WITH DOOR INSTALLATION
PRIOR TO INSTALLATION
MAKE SURE THESE
SCREWS ARE LOOSE.
INSTALL BUTTON HEAD SCREW
AS SHOWN, FLUSH WITH
BOTTOM SURFACE.
BOTTOM
SURFACE
