TRI tool 301SP - 10. TOOL BITS; 10.1 Tube Squaring Tool Bits for Standard Saddles

TRI TOOL INC.
92-0579 Rev. 190612
26
10. TOOL BITS
10.1 Tube Squaring Tool Bits for Standard Saddles
TUBE SQUARING TOOL BITS FOR STANDARD SADDLES
Range Max Wall Pipe or Tube Tool Bit Squaring Tool
Thickness Material Height Bit P/N
.125" OD thru 1.05" OD .125” CS SS .750” Durabit 1
(3.2mm OD thru (3.2mm) 316L (16.1mm)
26.7mm OD) SS
