Model 301SP Tube Squaring Machine
92-0579 Rev. 190612 33
Parts List, Model 301SP Sub-Assembly (P/N 02-2200)
Item Part Description Qty
No. No.
1. 19-0736 HOUSING ASSY., 301SP 1
2. 46-0014 SLEEVE 1
3. 41-0018 HANDLE,1.25"X3.19" 1
4. 14-0006 SHAFT ASSY. 1
5. 34-0059 WASHER,FLAT,1/2"X13/8" 1
6. 29-0028 BEARING,ROLLER,1/2"X11/16"X7/8" 2
7. 40-0035 SPRING, COMP., 1 11/16" X 1 3/4" 1
8. 30-0062 RING,RETAINING,EXT.,1/2"O.D. 1
9. 20-0016 SHAFT 1
10. 30-0063 RING,RETAINING,EXT.,13/8"O.D. 1
11. 46-0016 SLEEVE 1
12. 33-0499 SCREW, SET, 1/4 - 20 X 1/4", CUP PT. 3
13. 32-0026 PIN,ROLL,1/8"DIA.X3/4" 1
14. 30-2278 GRIP 1
15. 34-0060 WASHER,FLAT,1/2"X3/4"X1/8" 1
16. 33-0041 SCREW,CAP,1/4-20X7/8" 1
18. 33-0030 SCREW,CAP,#10-24X3/4" 3
19. 42-0146 KNOB ASSY., ADJUST 1
20. 33-1924 SCREW, SHOULDER, 1/4" X 1 1/2", 5/32", HEX 1
22. 46-0480 SLEEVE,INDICATOR 1
23. 33-0501 SCREW,SET,1/4-20X3/8",CUPPT. 1
24. 33-4131 SCREW,BUTTON,1/4-20X11/8" 2
25. 34-0304 WASHER, .265" I.D. X .750" O.D. X .090" THK. 2
26. 27-0614 ADAPTOR, INDICATOR 1
27. 33-0013 SCREW,CAP,#6-32X1/2" 2
28. 24-4554 PLATE,CHIPGUARD 2
29. 30-6428 INSERTNUT,1/4-20 2
30. 30-6429 SPACER,3/8"O.D.X3/16"I.D.X9/32" 5
31. 33-0316 SCREW,BUTTON,#10-32X1" 2
32. 48-4058 BLOCK,CHIPGUARD 1
33. 24-4555 PLATE, DOOR, CHIP GUARD 2
34. 30-6455 PIN, QUICK RELEASE W / LANYARD 1
35. 30-6456 SPACER, 1/2" X 3/16" X .252" I.D. 2
36. 33-4401 SCREW,BUTTON,#10-32X9/16" 1
37. 33-4402 SCREW, SHOULDER, MOD. 1
38. 35-0013 NUT,HEX,#10-32 1
39. 48-4119 BLOCK,HINGE,CHIPGUARD 1
