Trianco Contractor H.E. 50/90 EXTERNAL - Page 22

22
SPARES
Item Description 50/90 Qty 100/125 Qty
1 Boiler Body 222421 1 223971 1
2 Right Side Panel Assembly 223496 1 223506 1
3 Left Side Panel Assembly 223495 1 223505 1
4 Top Panel 210952 1 221712 1
5 Front Door 223493 1 223503 1
6 Back Panel 223497 1 223507 1
7 Condensing Unit 223880 1 223880 1
8 Boiler Control Thermostat 206896 1 206896 1
9 High-Limit Thermostat 206892 1 206892 1
10 Frost Thermostat 209735 1 209735 1
11 Control Box Assembly 210799 1 210799 1
12 Flue Assembly 223470 1 223470 1
13 Flue Sealing Gasket 223071 1 223071 1
14 Flue Gasket 223787 1 223787 1
14a
Top Baffle
1
208838 3 223965 1
15
Middle Baffle
1
- - 222984 2
16
Bottom Baffle
1
208834 1 223336 1
17 Baffle Access Cover 208803 1 208803 1
18 Burner 223868 1 223928 1
19 Burner Cover 223444 1 223444 1
20 Burner Cover Plate 223447 1 223447 1
21
Flexible Oil Line
2
207019 1 207019 1
22 Acoustic Hose 209491 1 209491 1
23 Burner Mounting Flange 223118 1 223118 1
24 Burner Mounting Gasket 223108 1 223108 1
25 Condensate Pipework 223939 1 223939 1
26 Return Pipework Assembly 222973 1 223987 1
27 Drain Cock 99592 1 99592 1
28 Condensate Unit Access Cover 223898 1 223898 1
29 Condensate Unit Access Cover Gasket 223899 1 223899 1
30 Air Box Spigot 223863 1 223969 1
31 Automatic Air Vent 207296 1 207296 1
32 Flue Seal Clamping Collar 223844 1 223844 1
33 Flue Sealing Rubber 223853 3 223853 3
34 Blanking Plate 223842 2 223842 2
35 Casing Grommet 210787 6 210787 6
36 Terminal Guard 223479 1 223479 1
1
See Fig. 16 (page 19) for baffle configurations.
2
See burner details leaflet for further information.
