Standby Mode
A
fter the boiler is turned on, the control panel will be in the
STANDBY mode.
This is the standard mode for the PRESTIGE. The control
automatically returns to this mode after 20 minutes if no
keys have been pressed on the display. Any parameters
that were modified are then stored.
The first character shows (on the left side of the display)
the current status of the boiler depending on the condition
of both the boiler and the burner. The last 3 characters
indicate the boiler supply temperature.
If the burner is blocked due to a “soft” lockout, the display
alternates between a 9 followed by the boiler supply tem-
perature and “b” with a two digit error code. See page 12
-17 for detailed information on the corrective and preven-
tive actions for the soft lockouts.
TO TEMPORARILY PLACE THE BURNER
INTO HIGH FIRE TEST MODE: press the MODE
button until “
StbY” is displayed. Then press and
hold both the MODE and “+” buttons simultaneous-
ly until the first digit flashes “H”.
While in the test mode:
- high limit will function
- boiler CH circulator will function
- domestic circulator will not function
- the test mode will time out in approximately
10 minutes
TO TEMPORARILY PLACE THE BURNER
INTO LOW FIRE TEST MODE: press the MODE
button until “
StbY” is displayed. Then press and
hold both MODE and “-” buttons simultaneously
until the first digit flashes “L”.
TO DEACTIVATE THE HIGH OR LOW FIRE
TEST MODE: press the MODE button until
“
StbY” is displayed. Then press and hold both the
“+” and “-” buttons simultaneously to deactivate the
high or low fire test mode.
If the “+” button is held in, the CH system
(parameter 3) will be turned OFF and the dis-
play will show “
cOFF”. Press and hold the “+”
button to turn the CH system back ON, the dis-
play will show “c” followed by CH set point. If
the “-” button is held in while in the “
StbY”
mode, domestic system (parameter 2) will be
turned OFF and the display will show “
dOFF”.
Press and hold “-” button to turn the domestic
system back ON, the display will show “d” fol-
lowed by domestic set point temperature.
S
tb
Y
NOTICE
Control Module Display - General
Internal check
Test function: Burner on, high fire mode
Test function: Burner on, low fire mode
A
18
0
18
0
18
0
H
L
Display
Boiler function
5

TriangleTube prestige Specifications

General

Manufacturer	Triangle Tube
Efficiency	Up to 95% AFUE
Heat Exchanger Material	Stainless Steel
Vent Type	Direct Vent
Model	Prestige
Category	Boiler
Fuel Type	Natural Gas, Propane
Modulation	Yes
Boiler Type	Condensing
Weight	Varies by model
Dimensions	Varies by model
Warranty	10 years heat exchanger
