CRYSTAL
10
5 Program
ð
Play
ð
DMX Receive
Slave Receive
ð
Part 1 Receive/Part 2 Receive/Part 3 Receive
Sequence
ð
Alone/Master
Music
ð
Alone/Master
Select Chase
ð
Chase Part 1
ð
Chase 1 - Chase 8
Chase Part 2
ð
Chase 1 - Chase 8
Chase Part 3
ð
Chase 1 - Chase 8
Edit Chases
ð
Edit Chase 1
ð
Chase Test/ Step 1 - Step 64
Edit Chase 2
ð
Chase Test/ Step 1 - Step 64
Edit Chase ...
ð
Chase Test/ Step 1 - Step 64
Edit Chase 8
ð
Chase Test/ Step 1 - Step 64
Edit Scenes
ð
Edit Scenes 001
ð
Control/.../Fade Time/Scene Time/External Input
Edit Scenes 002
ð
Control/Pan/Pan Fine/Tilt/Tilt Fine...
Edit Scenes ...
ð
Control/Pan/Pan Fine/Tilt/Tilt Fine...
Edit Scenes 250
ð
Control/Pan/Pan Fine/Tilt/Tilt Fine...
Scenes Record
ð
Sc XX - Sc XX
3.4 SLAVE RECEIVE MODE
This mode will allow you to link up the units together without a controller. Choose a unit to function as the
Master. The unit must be the first unit in line; other units will work as slave with the same effect.
A Master unit can send up to 3 different data groups to the Slave units, i.e. a Master unit can start 3 dif-
ferent Slave units, which run 3 different programs. The Master unit sends the 3 program parts in a conti-
nuous loop.
The Slave unit receives data from the Master unit according to the group which the Slave unit was assig-
ned to.
For example, if a slave device is set to Receive Part 1, the Master unit Slave unit will send the automated
Chase Part 1; if set to Receive Part 2, the Chase Part 2 Slave units will receive from the Master.
To set the drive as a slave, proceed as follows:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, and then select Play and press the ENTER
button to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, and select Slave Receive and press ENTER to
confirm.
• Press the UP/DOWN button to select the different modes of operation Part 1 Receive/Receive Part 2/Part 3
Receive, and then press the ENTER button to confirm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
Select the desired program on the master unit (described in section 3.5).
Use the DMX connectors of the CRYSTAL and an XLR cable to form a chain of units. Under certain conditions
and lengths you want to make a termination as shown on page 15.
