Tribe Crystal - Functions and Settings; Operation; Basic

7
CRYSTAL
- 3 - FUNCTIONS AND SETTINGS
3.1 OPERATION
Connect the supplied main cable to a socket (100-240V~/50-60Hz). The unit will run built-in program to
reset all motors to their home position. Shortly after that the CRYSTAL is ready for operation. To switch off,
disconnect the mains plug from the socket. For a more convenient operation it is recommended to con-
nect the unit to a socket which can be switched on and off via light switch.
3.2 BASIC
The CRYSTAL has a LCD display and 5 button used to access the control panel functions and manage them
(fig.4).
Fig.4 - Functions of the buttons and display icons
CONNECT
LIGHT
INFORMATION
SET
PROGRAM
LEFT
RIGHT UP DOWN ENTER
Used to navigates
through settings
value and to exit the
menu or to return a
previous menu option
Used to navigates
through settings
value
Navigates downwards
through the menu
list and increases the
numeric value when
in a function
Navigates upwards
through the menu
list and decreases the
numeric value when
in a function
Used to select and
enter the current
menu or confirm the
current function value
or option within a
menu
