Tribe Crystal - Page 19

17
CRYSTAL
MODE
FUNCTION DMX
Value
11 Ch
8
Reverse Spin
Stop to fastest 240 - 255
9
PRISM & PRISM ROT
Prism
3 facets prism (open)
Prism Rot Spin
Forward Slow to fastest
Stop
Reverse Slow to fastest
000 - 003
004 - 127
128 - 131
132 - 255
10
FOCUS
Continuous
Focus In to Focus Out 000 - 255
11
CONTROL
Normal
Reset All
Pan & Tilt Reset
Color Reset
Gobo Reset
TBD
Other Reset
Display Off
Dispaly On
TBD
Hibernation
TBD
000 - 007
008 - 015
016 - 023
024 - 031
032 - 039
040 - 047
048 - 055
056 - 063
064 - 071
072 - 087
088 - 095
096 - 255
13 CHANNELS - BASIC 16 BIT
MODE
FUNCTION DMX
Value
13 Ch
1
PAN
0~100% 000 - 255
2
PAN FINE
0~100% 000 - 255
3
TILT
0~100% 000 - 255
4
TILT FINE
0~100% 000 - 255
5
MOVEMENT SPEED
Fast to slow 000 - 255
6
SHUTTER
Shutter closed
Strobe effect slow to fast
No function (shutter open)
000 - 031
032 - 223
224 - 255
7
DIMMER
0~100% 000 - 255
8
COLOR
Indexed
Position 1 (open)
Position 2 (red)
Position 3 (blue)
Position 4 (green)
Position 5 (yellow)
Position 6 (pink)
Position 7 (sky blue)
Position 8 (orange)
Position 9 (magenta)
Indexed with Backout
Position 1 (open)
Position 2 (red)
Position 3 (blue)
Position 4 (green)
Position 5 (yellow)
Position 6 (pink)
Position 7 (sky blue)
Position 8 (orange)
Position 9 (magenta)
Indexed with Bounce
Position 1 (open)
Position 2 (red)
Position 3 (blue)
Position 4 (green)
000 - 005
006 - 011
012 - 017
018 - 023
024 - 029
030 - 035
036 - 041
042 - 047
048 - 053
054 - 059
060 - 065
066 - 071
072 - 077
078 - 083
084 - 089
090 - 095
096 - 101
102 - 106
107 - 119
120 - 132
133 - 145
146 - 158
