CRYSTAL
18 CHANNELS - EXTENDED
MODE
FUNCTION DMX
Value
18 Ch
1
PAN
0~100% 000 - 255
2
PAN FINE
0~100% 000 - 255
3
TILT
0~100% 000 - 255
4
TILT FINE
0~100% 000 - 255
5
MOVEMENT SPEED
Fast to slow 000 - 255
6
MOVEMENT FUNCTION
Normal
Movement with Backout
TBD
000 - 015
016 - 031
032 - 255
7
SHUTTER FUNCTION
Normal Shutter Functions
Pulse-effect Forward
Pulse-effect Reverse
Random Strobe
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 255
8
SHUTTER
Normal Shutter Functions
Close
Strobe Rate (slow to fast)
Open
Pulse-effect Forward
Close
Strobe Rate (slow to fast)
Open
Pulse-effect Reverse
Close
Strobe Rate (slow to fast)
Open
Random Strobe
Close
Strobe Rate (slow to fast)
Open
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
9
DIMMER
0~100% 000 - 255
10
COLOR FUNCTION
Indexed
Indexed with Backout
000 - 015
016 - 031
MODE
FUNCTION DMX
Value
18 Ch
10
Forward Spin
Reverse Spin
Continuous
Color Bounce
TBD
032 - 047
048 - 063
064 - 079
080 - 111
112 - 255
11
COLOR
Indexed & Indexed with Backout & Color
Bounce
Position 1 (open)
Position 2 (half open/half red)
Position 3 (red)
Position 4 (half red/half blue)
Position 5 (blue)
Position 6 (half blue/half green)
Position 7 (green)
Position 8 (half green/half yellow)
Position 9 (yellow)
Position 10 (half yellow/half pink)
Position 11 (pink)
Position 12 (half pink/half sky blue)
Position 13 (sky blue)
Position 14 (half sky blue/half orange)
Position 15 (orange)
Position 16 (half orange/half magenta)
Position 17 (magenta)
Position 18 (half magenta/half open)
Forward Spin
Stop to fast
Reverse Spin
Stop to fast
Continuous
Positioning from 0-360°
000 - 013
014 - 027
028 - 041
042 - 055
056 - 069
070 - 083
084 - 097
098 - 111
112 - 125
126 - 139
140 - 153
154 - 167
168 - 181
182 - 195
196 - 209
210 - 223
224 - 237
238 - 255
000 - 255
000 - 255
000 - 255
12
ROT GOBO FUNCTION
Indexed
Indexed with Backout
Forward Spin
Reverse Spin
Continuous
Shake
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 079
080 - 095
096 - 255
13
ROT GOBO
Indexed & Indexed with Backout &
Shake
Position 1 (open)
000 - 031
