___ 14. Check the phase rotation at the line side terminals located behind the back door
of the unit.
(On 3-phase units)
3.3 Monitoring System Check Out
___ 15. BASIC INDICATORS:
___ a. Turn ON the building power to the unit, then turn the main input
breaker ON.
___ 16. POWER MONITOR PANEL. If unit is equipped with a Power Monitor
Panel:
Turn the unit ON. Ensure that the voltage values indicated by the
Monitor Panel correspond to the voltage values measured at the input.
3.4 Equipment Connection Check Out (For Units With Distribution Cables)
All loads should be disconnected or turned off before proceeding with the
following steps.
For units with output distribution cables, be sure that there are NO output
receptacles connected to load equipment plugs, and that the receptacles are not
in contact with foreign objects.
Pay special attention to those output cables intended for direct-wiring
connection; the exposed conductor ends of these cables must not be in contact
with each other or with any foreign objects.
___ 17. Individually turn on each branch circuit breaker and check the output voltage
(also phase rotation, if a 3-phase circuit) at the receptacle or cable end.
___ 18. Turn OFF all branch circuit breakers.
___ 19. Connect the load equipment per equipment manufacturer’s specifications and
recommendations.
___ 20. Turn on branch circuit breakers to the load equipment.
Observe the power-up sequence recommended by the equipment
manufacturer.
___ 21. Verify that all load equipment operates properly.
After Inspection and Start-Up procedure is complete, the completed Start-Up and Inspection
form furnished with the unit should be signed and returned to:
Trilogy, Inc.
27068 La Paz Road # 701
Aliso Viejo, CA 92656
Warranty is not in effect unless the factory receives inspection and start-up form.
Customer Signature: ____________________ Date: ______________
