Trilogy INFINITY Series - Start-Up

13
3.0 Inspection and Start-Up Checklist
Unit Serial Number:
Unit Model Number:
Date:
_____________________________________________
_____________________________________________
_____________________________________________
3.1 Inspection
WARNING
ALL EQUIPMENT INSPECTION PROCEDURES ARE TO BE PERFORMED WITH
POWER TO THE UNIT TURNED OFF AND LOCKED OUT.
Exterior Inspection
___ 1. Confirm that the exterior of unit is undamaged (including cables and receptacles,
if furnished).
___ 2. Confirm that service and ventilation clearances are adequate.
Interior Inspection
___ 3. Inspect all wire and conductor insulation for damage.
___ 4. Check all breaker connections for tightness. Re-torque if necessary.
___ 5. Check all terminal block connections for tightness. Re-torque if necessary.
___ 6. Remove any foreign objects from the components or the interior area of the unit.
___ 7. Check that the side air screens are clean and free of obstructions.
3.2 Start-Up
WARNING
ONLY QUALIFIED PERSONNEL SHOULD PERFORM START-UP
PROCEDURES. HAZARDOUS VOLTAGES ARE PRESENT IN THE EQUIPMENT
THROUGHOUT THE MAJORITY OF THE START-UP PROCEDURE. USE
PROPER SAFETY EQUIPMENT. PROCEED WITH CAUTION.
___ 8. Make certain that all circuit breakers are in the OFF position and that power to
the unit is locked out.
___ 9. Verify proper input power connections to unit, including proper grounding
conductor.
___ 10. Turn ON the building input power to the unit.
___ 11. Check the phase rotation at the main input Lugs. Phase rotation should be A, B,
C, left-to-right. (On three phase units)
___ 12. Check and record the input voltage at the main input breaker/lugs. Measured
voltages should correspond to the unit’s nameplate input voltage.
Volts, phase A to phase B = _______________
Volts, phase B to phase C = _______________
Volts, phase C to phase A = _______________ (On 3-phase units)
___ 13. Turn ON the main input breaker (Located behind the front door, upper left),
should the breaker trips check for proper wiring. Contact TRILOGY or the
location factory representative for assistance.
