Compartment Light Activation
Compartment lights are activated upon unlocking compartment doors
(bank A-D) or toggling vehicle switch. The activation duration is
controlled via trim pot. Starting the engine deactivates the light.
Auxiliary ( * ) Output Activation
Standard Mode: With proper wiring and system configuration, Aux 1
output can be activated with the “STAR” or “GEAR” button on the
standard version e-FOB transmitter, via keypad, or toggled with vehicle
switch. Ask your dealer for the function that has been assigned to this
button and for adjustment of activation duration. This output ceases
when the preset time duration expires or if system detects that the
engine has started.
Teaching Additional Transmitter FOBs
There are 2 ways that the receiver can be put into e-FOB learn mode.
The first requires that a CAN keypad be connected to the network. This
option allows the module to be put into train mode without accessing the
module. The 2
nd
option requires access to the module. Up to (10)
transmitters can be trained at one time.
Option 1 (CAN keypad connected to network):
1. Hold the (5 / 6) (3) button of keypad for 5 seconds. The keypad
will beep and the LEDs will flash.
2. Enter authority code. The buzzer stays on.
3. Hold (9 / 0) (DB) for 5 seconds. A double-beep plays.
4. The receiver module is now in e-FOB learn mode. (The LED
under the receiver enclosure will be blinking rapidly).
5. Next press lock button of each transmitter to be trained. (LED
stays solid for 2 seconds as each one is trained.) Press the
transmitter button for 0.5-2.0 seconds. A three second delay
must occur between each transmitter.
6. After 60 seconds of e-FOB button inactivity, or by simply
pressing any key on the keypad, 4 beeps will sound and the
module will return to normal operation.
9
