TRIMOS V5 - V5 Specifications; V6 Specifications

V3 / V4 / V5 / V6 / V8
750 50 0045 03 47
V5 400 700 1100
Measuring range mm (in)
407 (16)
711 (28)
1110 (44)
Application range mm (in)
719 (28)
1023 (40)
1422 (56)
Max. permissible errors, B
MPE
µm
2.5 + L(mm)/300
Repeatability, R
MPE
µm
2
Perpendicularity deviation (frontal), S
MPE
µm
5
8
11
Max. resolution mm (in)
0.0005 (0.00005)
Measuring force N
0.75 ÷ 1.5
Autonomy h
12
Data output
USB / RS232
Air cushion
Yes
Protection grade of measuring system (CEI 60529)
IP67
Weight kg
21
24
33
Max. weight of measuring insert & holder g
400
Max. manual/motorised displacement speed mm/s
1000/70
Operational temperature °C
+10 ÷ +40
Storage temperature °C
-10 ÷ +40
Relative humidity (operation and storage) HR
5 ÷ 75 % (without condensation)
V6 400 700 1100
Measuring range mm (in)
407 (16)
711 (28)
1110 (44)
Application range mm (in)
719 (28)
1023 (40)
1422 (56)
Max. permissible errors, B
MPE
µm
2 + L(mm)/400
Repeatability, R
MPE
µm
1 (Ø: 2)
Perpendicularity deviation (frontal), S
MPE
µm
5
8
11
Max. resolution mm (in)
0.0001 (0.000005)
Measuring force N
0.75 ÷ 1.5
Autonomy h
12 *
Data output
USB / RS232
Air cushion
Yes
Protection grade of measuring system (CEI 60529)
IP40
Weight kg
21
24
33
Max. weight of measuring insert & holder g
400
Max. manual/motorised displacement speed mm/s
1000/70
Operational temperature °C
+10 ÷ +40
Storage temperature °C
-10 ÷ +40
Relative humidity (operation and storage) HR
5 ÷ 75 % (without condensation)
The above values have been determined according to ISO 13225 with the standard insert (TA-MI-101)
R
MPE
is defined as twice the standard deviation (2s) over 20 height measurements.
* If an electronic perpendicularity probe remains connected, the autonomy may decrease
