1-16 Introduction
System Building
Trio Motion Technology
Features and Typical Applications
Trio
BASIC contains accurate motion control functions for the generation of complex
movements of various types, including:
• Linear interpolation of up to 24 axes
• Circular and helical interpolation
• Variable speed and acceleration profiles
•Electronic gearboxes
• Electronic cam profiles
The operator interface may be achieved by any combination of the following:
• Dedicated host computer (connected via USB, Ethernet or RS-232 serial port)
• Membrane Keypad with Vacuum Fluorescent Display
• Dedicated Operator Panel using the’Modbus’ serial protocol.
• Switches / Thumbwheels
•Status lamps
The system is able to control a wide range of mechanisms and equipment including:
• Brushless servo motors
•Stepper motors
• Brushed DC servo motors
• Hydraulic servo valves
• Hydraulic proportional valves
• Pneumatic/hydraulic solenoids
•Relays/contactors
Typical applications:
• Cut to length • Coil winding • Automotive welding
• Flying shears • Laser guidance • Spark erosion
• Glue laying • Electronic assembly • Drilling
• Web control • Printing • Milling
• Tension control • Collating
• Pick & Place • Packaging • YOUR application
