Motion Coordinator Technical Reference Manual
Introduction 1-5
Products
Products
The range of Trio
Motion
Coordinator products covered by this manual:
Motion Coordinator Master Controllers
Product
Code
Name Description
P192 MC302X Compact, low cost DIN-rail mounting module features 1 1/2
servo or 2 stepper axes. 4 Opto-isolated Inputs and 4 Opto-
isolated I/O channels are built in user serial support RS232/
RS485. Multi-tasking Trio BASIC. I/O CANbus expansion.
P136 MC206X Low cost, high performance DIN-rail mounting controller for 1-8
axes with additional daughter board. 8 Opto-isolated Inputs
and 8 Opto-isolated Input/Output channels,1 Opto-isolated
analogue input, USB and memory stick socket are built in.
Multi-tasking Trio BASIC. I/O CANbus expansion.
P151 Euro
205x
For OEM applications, Trio offer a 3U Eurocard format controller
featuring 4 onboard axes plus the option for a further axis via a
standard Trio daughter board. 16 Opto-isolated Inputs and 8
Opto-isolated Output channels are built in. Multi-tasking Trio
BASIC. I/O CANbus expansion.
P159 Euro 209
For OEM applications, Trio offer a 3U Eurocard format controller
featuring 8 onboard axes plus the option for a further axis via a
standard Trio daughter board. 16 Opto-isolated Inputs and 8
Opto-isolated Output channels are built in. Multi-tasking Trio
BASIC. I/O CANbus expansion. Motion Perfect programming via
Ethernet ports.
P170 MC224 Flexible high performance master controller for 1-24 axes. 8
Opto-isolated Inputs and 8 Opto-isolated Input/Output
channels, 2 Opto-isolated analogue inputs, USB and memory
stick socket are built in. Multi-tasking Trio BASIC. I/O CANbus
expansion.
