1-8 Introduction
Products
Trio Motion Technology
P280 Differential
Stepper
Differential Line Driver outputs for Step, Direction,
Boost and Enable, plus Hardware Registration Input
The Differential Stepper daughter board is a stepper
daughter board with the output signals provided as dif-
ferential 5 volt signals on a 15 way 'D' connector. The
daughter board does not feature an encoder port for
position verification, but does have a registration input
to allow for capture of the number of step pulses when
a registration signals arrives.
P290 /
P293
CAN Digital Link to CANBus drives
The CAN daughter board provides synchronous control
of up to four axes using the CanOpen protocol. Alterna-
tively, it can be set up as a DeviceNet slave node, or
may use the can directly from Trio Basic.
P291 SERCOS Digital Link to SERCOS drives
The SERCOS daughter board provids digital control to
appropriate servo drives via a Fibre Optic loop. Up to 8
axes can be connected to each P291, which allows the
MC224 to control up to 24 axes.
P292 SLM Digital Link to SLM drives
The SLM daughter board is aimed at providing digital
control channels for servo drives utilising the SLM proto-
col.
P295 USB Interface Universal Serial bus interface for high-speed PC
communications
The USB daughter board provides a high speed interface
between the Euro205x and Euro 209 and a host PC fitted
with a USB port. Support for this high speed interface is
included in Trio's MotionPerfect 2 application and soft-
ware libraries allow developers to support the interface
within their own programs.
Product
Code:
Name Description
