3- In case the battery cable connected to the motor is not inside the front box of the
bike, pass it through the hole. Then connect every wire with the wires that come from the
battery dock:
- RED with RED
- BLACK with BLACK
- WHITE with WHITE
IMPORTANT:
Don’t connect the cables when the battery is connected to the dock.
Don’t invert the cables, this will short circuit the system and it’s
extremely dangerous!
4- Push the wires inside the hollow space contained by the 2 halves of the battery dock.
The 2 halves need to be first merged together (they’ve a dent) and then connected to the
battery dock.
20
21
MOUNTING THE BATTERY MOUNTING THE BATTERY
