The following section is to be used by a qualified HVAC
contractor or installer ONLY.
These procedures are not to be attempted by any person
not qualified to work with high voltage or familiar with the
installation of this type of air cleaner. Seller cannot be held
responsible for any injury or damage by any person not
qualified to install this product.
INSTALLER HELP LINE
If you have any questions on installation issues or problems, please call
Technical Support 800-884-0002
Installation
For Qualified HVAC
Installer Only
1
1
Model
Size
Part Number 120V/50-60Hz
Part Number 240V/50-60Hz
Maximum Rated Airflow
Maximum Pressure Drop
Cell Weight
(2 Cells in ea. unit)
Unit Weight
Maximum Power
Consumption
Electrical Output
Classification
Optional Accessories
HE Plus 1400
(16x25)
455601-001
455601-010
1400 CFM (2380m/hr)
.11 inch w.g. @1400 CFM
10 lbs ea. (4.5 kg)
32 lbs. (14.6 kg)
40 watts
2.5 MADC @ 6200 VDC
UL/CE
Charcoal After Filter
HE Plus 1400
(20x20)
455603-001
455603-010
1400 CFM (2380m/hr)
.11 inch w.g. @1400 CFM
9 lbs ea. (4.1 kg)
36 lbs. (16.4 kg)
40 watts
2.5 MADC @ 6200 VDC
UL/CE
Charcoal After Filter
HE Plus 2000
(20x25)
455600-001
455600-010
2000 CFM (3400m/hr)
.14 inch w.g. @2000 CFM
12 lbs ea. (5.5 kg)
36 lbs. (16.4 kg)
48 watts
3.2 MADC @ 6200 VDC
UL/CE
Charcoal After Filter
Technical Specifications
