INSTALLATION
CAUTION:
Only a trained, experienced servicer should install this Electronic Air Cleaner. The
Front Panel Assembly, Power Tray Assembly, Ionizing-Collecting Cells and Pre-filters
should be removed before installation. To remove the Power Tray Assembly, remove
the two (2) screws from inside the top front of the cabinet. Keep this hardware for re-
installation of the Power Tray Assembly after the air cleaner installation is completed
and before operation. A thorough check-out of the unit installation should be
completed before operation of the air cleaner.
INSTALLER HELP LINE
If you have any questions on installation issues or problems, please call
Technical Support 800-884-0002
Prior to installing this Electronic Air Cleaner:
1. Read instructions carefully for safe operation. Failure to follow instructions can
damage the product or cause a hazardous condition and may result in physical harm.
2. Check the ratings stated on the product data label to make sure it is suitable for your
application.
3. Select a location for the air cleaner.
4. Remove the old furnace filter and discard.
5. The air cleaner cannot remove existing dirt from the blower and ducts. Clean the area
thoroughly before you begin installation.
6. Remove unit’s Front Panel Assembly and slide the Pre-filters and Ionizing-Collecting
Cells out of the cabinet. Remove the Power Tray Assembly and place ALL
components safely aside. Also, remove and discard cardboard shipping inserts from
inside Front Panel Assembly and bottom of cabinet.
PHYSICAL INSTALLATION OF THE AIR CLEANER
This Electronic Air Cleaner can be installed in any position, except with the Front Panel
Assembly facing UP or DOWN. The section TYPICAL MOUNTING POSITIONS illustrates
examples of proper air cleaner mounting with a variety of furnace installations.
Installation
16
For Qualified HVAC
Installer Only
