Triplett CM200 - Specifications: Capacitance, Diode, and General; Capacitance Specifications; Diode and Continuity Specifications; General Specifications

Function
Range
Resolution
Accuracy ±(% of
reading+digits)
Capacitance
60.00nF
0.01nF
±(3% + 5 digits)
600.0nF
0.1nF
6.000µF
1nF
60.00µF
0.01µF
600.0µF
0.1µF
±(3.5% + 10 digits)
4000µF
1µF
±(5.0% + 10 digits)
* >6nF no specification; Over Rang Protection: 300V rms
Function
Testing Condition
Reading
Diode
Test current of 1.5mA typical;
Open circuit voltage <3VDC typical
Forward voltage drop
of Diode.
Continuity
Test current <0.35mA
Buzzer makes a long
sound, While
resistance is less
than(50Ω).
Over Rang Protection: 300V rms
Note: Accuracy is given as ±(% of reading + counts of least significant digit) at 23
o
C /±5 ,
with relative humidity less than 80%RH.
General Specifications
Clamp jaw opening 0.6" (16mm) approx.
Display (6000 counts) Negative Polarity LCD
Low Battery indication ‘ ’’is displayed
Diode Test Test Current of 0.35mA typical; Open Circuit
<3VDC Typical.
Over-range indication ‘OL’ display
Measurement Rate 3 readings per second, nominal
