17
HARDWIRED MODELS: APS2012UL
Series Number: AGAP200012MV2
Weight: 38.8 lbs.
Regulatory Approval: UL458
INVERTER
Continuous power (@ 20° C): 2000 W
Surge power (5 seconds): 4000 W
Efficiency (Full Load): 87%
Minimum/Maximum DC Fuse Rating: 300A/500A
DC Input Current @ Nominal V DC
Full Load 192 A
No Load 2.5 A*
Nominal Input Volts: 12 VDC:
DC Input Voltage Range: 10-15 VDC
Nominal Output Volts: 120 VAC ±5%
Nominal Output Frequency: 60 Hz ±.3%
BATTERY CHARGER
Charging Capacity DC: 20 A**
Acceptance Volts VDC: Selectable
14.4 V**/14.2 V Wet**/Gel
Float Volts VDC (w/gel): 13.3 V (13.6 V)
Input Voltage AC: 120 V
Input Current AC: 4.2 A**
LINE VAC OPERATION
Minimum Input AC Volts: Selectable 75**,85, 95, or 105 VAC
Maximum Input AC Volts
(Continuous, Charger at Maximum): Selectable 135** or 145 VAC
Maximum Input Current
(Continuous, Charger at Maximum): 29 A
Input Frequency: 60 Hz ±10%
Maximum Output AC (Continuous) 16.7 A
Automatic Transfer Time: 4-6 ms
* Load sense can reduce this to 1/30 of the listed current. ** Factory default setting. .
Specifications
(Hardwired Models)
