Standard Extender Kit Installation
1. Make sure all equipment in the installation—such as monitors, the
DisplayPort source and the transmitter—is powered OFF.
2. Using a DisplayPort cable, connect the DisplayPort source to the
INPUT port on the local transmitter unit.
3. Using an HDMI cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect a local monitor to the LOCALOUT
port on the B127A-1A1-BDBD local transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit
to the RJ45 port on the remote receiver unit.
5. Optional: To extend the transmission distance up to 400 ft., connect a
B127A-010-H signal booster (sold separately) between the transmitter
and receiver using Cat6 cable.
6. Using a DisplayPort cable, connect the remote receiver unit’s
DisplayPort port to a monitor.
7. Turn the power on to your connected TVs/monitors.
8. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED on the local transmitter unit
will illuminate to indicate the unit is receiving power from the external
power supply. The POWER (green) LED on the remote receiver unit
will illuminate to indicate the unit is receiving power from the local
transmitter unit through PoC technology.
9. Turn on the power to the DisplayPort source.
10. The (orange) RJ45 LED will illuminate on both the local transmitter
and remote receiver units to indicate a signal is being received from
the source to display. The screen should now display on the
connected monitor.
