Tripp Lite MODBUSCARD - Battery Status; Input Status

10
Operation
Battery Status
Description Address Value Unit
Battery Condition 0x041E
0: Good
1: Weak
2: Replace
Battery Status 0x041F
0: OK
1: Low
2: Depleted
Battery Charge 0x0420
0: Floating
1: Charging
2: Resting
3: Discharging
Seconds on Battery 0x0421 0-65534 Seconds
Estimated Minutes Remaining 0x0422 0-999
Estimated Charge Remaining 0x0423 0-999
Battery Voltage 0x0424 0-9999 0.1 Voltage
Battery Current 0x0425 0-9999 0.1 Amp
Temperature 0x0426 0-999 Degrees Celsius
Battery Level 0x0427 0-999 %
External Battery Pack # 0x0428 0-10
Negative Battery Voltage 0x0429 0-9999 0.1 Voltage
Negative Battery Current 0x042A 0-9999 0.1 Amp
Negative Battery Temp 0x042B 0-999 Degrees Celsius
Negative Battery Level 0x042C 0-999 %
Reserved 0x042D
Reserved 0x042E
Reserved 0x042F
Input Status
Description Address Value Unit
Input Number Lines 0x0430 0-9
Input Frequency 1 0x0431 0-999 0.1 Hz
Input Voltage 1 0x0432 0-9999 0.1 Voltage
Input Current 1 0x0433 0-9999 0.1 Amp
Input Power 1 0x0434 0-65534 10 Watt
Input Frequency 2 0x0435 0-999 0.1 Hz
Input Voltage 2 0x0436 0-9999 0.1 Voltage
Input Current 2 0x0437 0-9999 0.1 Amp
Input Power 2 0x0438 0-65534 10 Watt
Input Frequency 3 0x0439 0-999 0.1 Hz
Input Voltage 3 0x043A 0-9999 0.1 Voltage
Input Current 3 0x043B 0-9999 0.1 Amp
Input Power 3 0x043C 0-65534 10 Watt
Input Voltage 12 0x043D 0-9999 0.1 Voltage
Input Voltage 23 0x043E 0-9999 0.1 Voltage
Input Voltage 31 0x043F 0-9999 0.1 Voltage
Reserved 0x0440
Reserved 0x0441
