Operation
Output Status
Description Address Value Unit
Output Source 0x0442
0: Normal
1: Battery
2: Bypass (Reserve)
3: Reducing
4: Boosting
5: Manual Bypass
6: Other
7: None
Output Frequency 0x0443 0-999 0.1 Hz
Output Number Lines 0x0444 0-9
Output Voltage 1 0x0445 0-9999 0.1 Voltage
Output Current 1 0x0446 0-9999 0.1 Amp
Output Power 1 0x0447 0-65534 10 Watt
Output Load 1 0x0448 0-999 %
Output Voltage 2 0x0449 0-9999 0.1 Voltage
Output Current 2 0x044A 0-9999 0.1 Amp
Output Power 2 0x044B 0-65534 10 Watt
Output Load 2 0x044C 0-999 %
Output Voltage 3 0x044D 0-9999 0.1 Voltage
Output Current 3 0x044E 0-9999 0.1 Amp
Output Power 3 0x044F 0-65534 10 Watt
Output Load 3 0x0450 0-999 %
Output Voltage 12 0x0451 0-9999 0.1 Voltage
Output Voltage 23 0x0452 0-9999 0.1 Voltage
Output Voltage 31 0x0453 0-9999 0.1 Voltage
Reserved 0x0454
Reserved 0x0455
Bypass Status
Description Address Value Unit
Bypass Frequency 0x0456 0-999 0.1 Hz
Bypass Number Lines 0x0457 0-9
Bypass Voltage 1 0x0458 0-9999 0.1 Voltage
Bypass Current 1 0x0459 0-9999 0.1 Amp
Bypass Power 1 0x045A 0-65534 10 Watt
Bypass Voltage 2 0x045B 0-9999 0.1 Voltage
Bypass Current 2 0x045C 0-9999 0.1 Amp
Bypass Power 2 0x045D 0-65534 10 Watt
Bypass Voltage 3 0x045E 0-9999 0.1 Voltage
Bypass Current 3 0x045F 0-9999 0.1 Amp
Bypass Power 3 0x0460 0-65534 10 Watt
Bypass Voltage 12 0x0461 0-9999 0.1 Voltage
Bypass Voltage 23 0x0462 0-9999 0.1 Voltage
Bypass Voltage 31 0x0463 0-9999 0.1 Voltage
Bypass STS Temperature 0x0464 0-999 Degrees Celsius
Reserved 0x0465
Reserved 0x0466
