12
Operation
Test Status
Description Address Value Unit
Test Result 0x0467
0: No Test Performed
1: Test Passed
2: Test In Progress
3: General Test Fault
4: Battery Test Fault
5: Deep Battery Test Fault
6: Test Aborted
Output Relay
Description Address Value Unit
Number of Output Relay 0x0468
0: Not Available
>0: Available (<=99)
Environment
Description Address Value Unit
Temperature 0x0469 0-999 Degrees Celsius
Humidity 0x046A 0-999
Relay 1 0x046B 0: Off, 1: On
Relay 2 0x046C 0: Off, 1: On
Relay 3 0x046D 0: Off, 1: On
Relay 4 0x046E 0: Off, 1: On
Reserved 0x046F
Reserved 0x0470
Select Voltage
Description Address Value Unit
Selected Output Voltage 0x0471 0-999 Voltage
Select Output Voltage 1 0x0472 0-999 Voltage
Select Output Voltage 2 0x0473 0-999 Voltage
Select Output Voltage 3 0x0474 0-999 Voltage
SRAM Exist
Description Address Value Unit
SRAM EXIST 0x0475 0: Doesn’t Exist 1: Exists
Note: Currently, this field is not supported by UPS.
