14
Temp Byte 15 (Lo): B0: TR1 Over Temperature
(O/P TR Over Heat Shutdown)
B1: TR2 Input Choke Over Heat
(I/P TR Over Heat Shutdown)
B2: Rectifier Over Temperature Warning
(>=75C)
B3: Rectifier Over Temperature
Shutdown (>=85C)
B4: Static Switch Over Temperature
Warning (>=75C)
B5: Static Switch Over Temperature
Shutdown (>=85C)
B6: Static Switch Overload
B7: Static Switch Fail
Temp Byte 16 (Hi): B0: Converter Board Power Abnormal
B1: EPO Happened
B2: Manual Bypass On
B3: Converter Board Communication
Error
B4: Battery Cabinet Over Temperature
Warning (>=75C)
B5: Battery Ground Fault
B6: Battery Test in Progress
B7: Battery Test Fail
Temp Byte 17: Reserved
Temp Byte 18: Reserved
Temp Byte 19: Reserved
Temp Byte 20 (Hi): B5: Ambiance Over Temperature
B7: Auxiliary Power Fail
Note: Currently, TempStatus is not supported by UPS.
Operation
Parallel Master ID
Description Address Value Unit
Parallel Master ID 0x0482 0 - 99
Available Event Log
Description Address Value Unit
UPS Event Log 0x0483 0-500
Event Log Report Format 0x0484 0-1
Event Reporting Method 0x0485 0-1
Event Log Report Format: 0: NT 9 byte format
1: NH 8 byte format
Power Module Attribute
Description Address Value Unit
Power Module ID / Attribute 0x0486 Lo: ID (1-4), Hi: Attribute
Power Module ID / Attribute 0x0487
Power Module ID / Attribute 0x0488
Power Module ID / Attribute 0x0489
Reserved 0x048A
Reserved 0x048B
Power Module Attribute: which is used to identify the attribute of the power module.
B0: PFC
B1: Rectifier
B2: Charger
B3: Inverter
B4: Bypass
B5: TBD
B6: TBD
B7: TBD
