Tripp Lite MODBUSCARD - Power Module Inverter Voltage

18
Operation
Power Module Inverter Voltage
Description Address Value Unit
Power Module ID 0x04DA 1-4
Inverter Voltage R 0x04DB 0-9999 0.1 Voltage
Inverter Voltage S 0x04DC 0-9999 0.1 Voltage
Inverter Voltage T 0x04DD 0-9999 0.1 Voltage
Power Module ID 0x04DE 1-4
Inverter Voltage R 0x04DB 0-9999 0.1 Voltage
Inverter Voltage S 0x04DC 0-9999 0.1 Voltage
Inverter Voltage T 0x04DD 0-9999 0.1 Voltage
Power Module ID 0x04DE 1-4
Inverter Voltage R 0x04DF 0-9999 0.1 Voltage
Inverter Voltage S 0x04E0 0-9999 0.1 Voltage
Inverter Voltage T 0x04E1 0-9999 0.1 Voltage
Power Module ID 0x04E2 1-4
Inverter Voltage R 0x04E3 0-9999 0.1 Voltage
Inverter Voltage S 0x04E4 0-9999 0.1 Voltage
Inverter Voltage T 0x04E5 0-9999 0.1 Voltage
Power Module ID 0x04E6 1-4
Inverter Voltage R 0x04E7 0-9999 0.1 Voltage
Inverter Voltage S 0x04E8 0-9999 0.1 Voltage
Inverter Voltage T 0x04E9 0-9999 0.1 Voltage
Reserved 0x04EA
Reserved 0x04EB
Reserved 0x04EC
Reserved 0x04ED
Reserved 0x04EE
Reserved 0x04EF
Reserved 0x04F0
Reserved 0x04F1
Battery Cabinet Temperature
Description Address Value Unit
Battery Cabinet #1 Temperature 0x04F2 0 – 999 Degrees Celsius
Battery Cabinet #2 Temperature 0x04F3 0 – 999 Degrees Celsius
Battery Cabinet #3 Temperature 0x04F4 0 – 999 Degrees Celsius
Battery Cabinet #4 Temperature 0x04F5 0 – 999 Degrees Celsius
Reserved 0x04F6
Reserved 0x04F7
