LED Indicators
NGI-U05C2POE4 and NGI-U05POE4
LED (Color) Status Description
PWR (Green)
Illuminated
Power On by terminal block PWR
or 4-pin mini DIN connector.
O
Terminal block PWR/4-pin mini
DIN connector is not available.
POE 1-4 (Green)
Illuminated Supplying power to PD devices.
O
No power supplied to PD
devices.
1000 (Mbps)
Illuminated
Copper ports communicate at
1000Mbps speed.
O
Copper ports communicate at
10/100Mbps speed.
LNK/ACT (Green)
Illuminated Ethernet link is up.
Blinking
Activity (receiving or transmitting
data).
O Port disconnected or link failed.
SFP
NGI-U05C2POE4
(Green)
Illuminated Data is transmitting / receiving.
O Port disconnected or link failed.
To Next Page
