LED Indicators
NGI-U08C2POE8
LED (Color) Status Description
PWR (Green)
Illuminated Primary Power is connected.
O󰀨
Primary Power failure or not
available.
RPS (Green)
Illuminated Redundant Power is connected.
O󰀨
Redundant Power failure or not
available.
ALM (Red)
Illuminated
Alarm for no Primary power or
Low I/P voltage.
O󰀨
No alarm to report or DIP
function is disabled.
PoE 1-8 Ports
(Green)
Illuminated
PoE power is delivered to the
powered device (PD).
O󰀨
PoE power feeding is not
functioning.
1000 (Green)
Illuminated Link on 1000Mbps.
O󰀨 Link on 100Mbps or 10Mbps.
LNK/ACT (Green)
Illuminated Ethernet link is up.
Blinking
Activity (receiving or transmitting
data).
O󰀨 Port disconnected or link failed.
SFP (Green)
Illuminated Data is transmitting / receiving.
O󰀨 Port disconnected or link failed.
