5. Operation
5.6 STATUS Menu
The STATUS menu provides information on current operating conditions. Touch the
down arrow to access sub-menus.
The rst sub-menu provides:
• Operating mode
• Cooling output (estimated in kW)
• Temperature of the air entering the SRCOOL33K/SRXCOOL33K
• Temperature of the air leaving the SRCOOL33K/SRXCOOL33K
The second sub-menu provides:
• Temperature at the remote sensor
• Temperature of the air entering the condenser
• Temperature of the air leaving the condenser
The third sub-menu provides:
• Refrigerant pressure at the compressor inlet
• Discharge pressure at the compressor outlet
• Temperature of the refrigerant entering the compressor
• Temperature at the evaporator
The fourth sub-menu provides:
• Speed of the fans that regulate evaporator air flow
• Speed of the fans that regulate condenser air flow
• Frequency of compressor operation (in Hz)
• Electronic expansion valve position
The fth sub-menu provides:
• Current the compressor is drawing
• Current the fans are drawing
• Total current for the unit
The sixth and seventh sub-menus provide the time the following components
have been in use:
• Air filter
• Evaporator fan
• Condenser fan
• Compressor
• Condensate pump
• Atomizer

  
  
  
  
  
   
  
  
  
  
  
   
   
  
  
  
  
  
  
 
  
 
  
  
  
 
  
 

  
  
  
  
  
   
  
  
  
  
  
   
   
  
  
  
  
  
  
 
  
 
  
  
  
 
  
 

  
  
  
  
  
   
  
  
  
  
  
   
   
  
  
  
  
  
  
 
  
 
  
  
  
 
  
 

  
  
  
  
  
   
  
  
  
  
  
   
   
  
  
  
  
  
  
 
  
 
  
  
  
 
  
 

  
  
  
  
  
   
  
  
  
  
  
   
   
  
  
  
  
  
  
 
  
 
  
  
  
 
  
 
