Troubleshooting
Problem Possible cause Solution
Shutter on Power Switch with Lock-Out Cover (3) not
releasing
Router is plunged to full depth – in collet lock position Reduce plunge depth
Inaccurate cutting profile Depth Stop not correctly adjusted Ensure that the Depth Stop corresponds to the maximum
amount of cut permitted by the Turret Stops (9)
Incorrectly fitted or loose router bit/Collet (5) Tighten router bit/Collet and cutter assembly
Router will not operate No supply of power Check that power is available at source
Brushes worn or sticking Disconnect power, open Brush Caps (20) and ensure brushes
are not damaged or heavily worn
Power Switch with Lock-Out Cover (3) is faulty Have the tool serviced by an authorised Triton service centre
Motor components faulty or short circuited Have the tool serviced by an authorised Triton service centre
Router runs or cuts slowly Blunt or damaged cutter Resharpen or replace cutter
Speed Controller (1) set low Increase variable speed setting
Motor is overloaded Reduce pushing force on router
Excessive vibration Incorrectly fitted or loose router bit Refit or tighten router bit
Bent or damaged router bit Replace router bit
Heavy sparking occurs inside motor housing Brushes not moving freely Disconnect power, remove brushes, clean or replace
Damaged or worn motor Have the tool serviced by an authorised Triton service centre
Micro Winder (8) “clicks” or not adjusting Plunge Lock Lever (7) engaged Release Plunge Lock Lever
Reached end of adjustment range Reset Micro Winder and set depth with the Depth Stop (11)
Makes an unusual sound Mechanical obstruction Have the tool serviced by an authorised Triton service centre
Damage to internal windings Have the tool serviced by an authorised Triton service centre
