9
Forte
wall is plasterboard or a soft building block, you
must use suitable wall plugs and an appropriate
drill bit.)
Screw the top fixing screw into position leaving
the base of the screw head protruding 6 mm out
from the wall.
Hook the backplate over the top screw and fit
the bottom fixing screw into position.
DO NOT fully tighten the screws at this stage,
as the fixing holes are elongated to allow for
out of square adjustment after the plumbing
connections have been completed.
Fig.10
